Incoming line specification:ø0.5～1.04mm
Outlet specification:ø0.10 ~ ø0.35mm
Maximum speed:Max. 1300m/min
Owing to the structure restriction of this wire drawing machine, it is more suitable for drawing wires of smaller diameters.
Wet wire drawing machine is available for drawing mild steel, carbon steel, stainless steel, copper, aluminum and alloys.
| NO | DETAIL CONTENT | TECHNICAL DATA |
| 1 | Max Dies Quantity | 25 Dies |
| 2 | Main motor power | 15-22-30 KW |
| 3 | Take-up motor power | 5.5 KW |
| 4 | Incoming line strength | ≤1280 Mpa |
| 5 | Incoming line specification | ø0.5～1.04mm |
| 6 | Outlet specification | ø0.10 ~ ø0.35mm |
| 7 | Maximum speed | Max. 1300m/min |
| 8 | Lubrication method | Intrusive, with spray, centralized supply |
| 9 | Outline size | 2385mm*1240mm*1830mm |
| 10 | Weight | 4.0 T |
